Mini High Efficiency Ultra Small Size DC-DC Step-Down Module 12V-24V To 5V3A Car
Mini High Efficiency Ultra Small Size DC-DC Step-Down Module 12V-24V To 5V3A Car
Sale
Sold out
Pre-order
Regular price
R 140.00
Regular price
Sale price
R 140.00
Unit price
per
Available to order
Processing time: 1-3 days
Couldn't load pickup availability
Estimated delivery: 6-13 working days
Ships from China (Standard) • Import Taxes & Duties Included
Description
The Mini High Efficiency Ultra Small Size DC-DC Step-Down Module converts input voltages from 12V-24V to a stable 5V output. It is suitable for applications requiring a compact voltage regulator, such as powering Arduino projects.
- Product Type: DC-DC Step-Down Module
- Compatibility: 12V-24V input voltage
- Material: Durable
- Size: 20mm x 11mm x 5mm
- Input Voltage: DC 4.5V - 24V
- Output Voltage: Adjustable (0.8V - 17V) and fixed (1.8V, 2.5V, 3.3V, 5V, 9V, 12V)
- Output Current: Maximum 3A (requires attention to heat dissipation)
- Conversion Efficiency: Up to 97.5% (at 6.5V to 5V, 0.7A)
- Switching Frequency: 500KHz
- Output Ripple: 20mV (12V to 5V at 3A, 20M bandwidth)
- Wiring Method: Welding
- Input Method: Welding
- Output Method: Welding / Pin Header
- Welding Hole Spacing: 2.54mm
- Output Over Voltage Protection: None
- Full Load Temperature Rise: 40°C
- Quiescent Current: 0.85mA
- Load Adjustment Rate: ±1%
- Voltage Regulation Rate: ±0.5%
- Dynamic Response Speed: 5% at 200µs
